Standard crankshaft bearings for Honda Civic B16A2

Standard crankshaft bearings for Honda Civic B16A2

ACL Trimetal bearings (hardened steel + copper + nickel) are designed for racing use. They reduce friction, improve operating temperatures and optimise oiling.

The ACL-5M1959H-STD model is specially designed for Honda Civic B16A2 engines, offering perfect tolerance for precise connecting rod adjustment.

These bearings are offered in STD rib and also in repair rib.

Specifications :

Supplier reference: ACL-5M1959H-STD

Tolerance: Standard size (STD)

Material: Tri-metal alloy (copper, lead, tin)

Recommended use: Motorsport, competition, engine preparation

Advantages : Increased abrasion resistance, optimum heat dissipation, precise fit

Dimensions:

Maximum overall length: 20 mm

Minimum axle size: 54.980 mm

Maximum axle size: 55 mm

Minimum tunnel size: 59 mm

Max tunnel size: 59,020 mm

Max wall to crown: 2,002 mm

Minimum vertical oil clearance:

Max vertical oil clearance:

Compatibility:

HONDA / ACURA

- B16A - 1595cc 4 Cyl

- B17A1/B18A1/B18B1/B18B2 - 1678cc/1834cc 4 Cyl

- B18C1 /B18C2/B18C5/B18C7 - 1797cc 4 Cyl VTEC

- B20B/B20Z - 1972cc 4 Cyl

- K20A3 - 1998cc 4 Cyl

- K20A2 / K20Z1 / K24A / K24Z1 - 1998cc/2354cc 4 Cyl
