- 8 User Configurable Channels (no Laptop required)
- Selectable current settings of 5, 10 or 15 Amps. Combine two channels together for 20, 25 or 30 Amps
- Selectable Functions such as
=>Momentary action (Starter Motor, Washer Pump etc)
=> Latching (with memory)
=> Latching (without memory)
=> Latching with Time Delay (Heated Screen)
=> Flashing (Indicators etc)
=> Toggling (Headlights High Beam/Low Beam)
=> 0v Momentary action (use as ordinary switch for ECU Map etc)
- Over Current and Short Circuit Protection - no Fuses or Relays needed.
- Multi coloured Label Sheet included for full customisation.
- 2 Back light settings as standard.
- 8 Momentary Switch Inputs - allowing any channel to be operated by an additional switch or the CARTEK Wireless Control System.
- 8 ECU Inputs - allows the ECU to turn on channels such as Fuel Pumps.
- 4 Dedicated function inputs - Flash Input for Lights, Wash Input for Wipers, Wiper Park position etc.
? 16 User Configurable Channels (no Laptop required)
? Selectable current settings of 5, 10 or 15 Amps. Combine two channels together for 20, 25 or 30 Amps
? Selectable Functions such as
-Momentary action (Starter Motor, Washer Pump etc)
-Latching (with memory)
-Latching (without memory)
-Latching with Time Delay (Heated Screen)
-Flashing (Indicators etc)
-Toggling (Headlights High Beam/Low Beam)
-0v Momentary action (use as ordinary switch for ECU Map etc)
? Over Current and Short Circuit Protection - no Fuses or Relays needed.
? Multi coloured Label Sheet included for full customisation.
? 2 Back light settings as standard.
? 16 Momentary Switch Inputs - allowing any channel to be operated by an additional switch or the CARTEK Wireless Control System.
? 16 ECU Inputs - allows the ECU to turn on channels such as Fuel Pumps.
? 4 Dedicated function inputs - Flash Input for Lights, Wash Input for Wipers, Wiper Park position etc.
