Ball seal Competition Rodobal Male Eye .8750 Thread 1" - RO-RXAM-14T-1 - RXAM-14T-1 - 3661768431290

Ball seal Competition Rodobal Male Eye .8750 Thread 1"

Reference: RO-RXAM-14T-1

Supplier Ref.: RXAM-14T-1

Learn more

€451.35 Tax included

€531.00 -15% Discount

Promotion ends in: 23 H 48 M 45 S

Available to order

Unavailable in store (Montpellier)

Within 20 days on average.

€531.00 -15%

€451.35 (tax incl.)

Earn 451 loyalty points (that is €15.00 in vouchers)

Carbon footprint: 0.44 kg CO₂

Ball seal Competition Rodobal Male Eye .8750 Thread 1"

The Rodobal RXAM-14T-1 competition ball joint is a high-end part designed to meet the most extreme demands of motor sports. Featuring a 0.875’ eye (22.225 mm) and a 1"-14 UNS-3A male thread on the right, it ensures a solid fit and smooth articulation in suspension or steering systems.

This precision-machined ball joint guarantees perfect stability even under static radial loads of up to 84,897 lbs (377,622 N). Thanks to the absence of preload, the ball joint moves freely from the start, which is ideal for easy suspension adjustment. It can also tilt up to 5.7°, allowing it to follow the movements of the bodywork without interfering with operation.

Features:

Bore: 0.875" (22.225 mm)

Thread: 1″-14 UNS-3A, right

Thread length: 1.875″ (47.63 mm)

Ball joint width: 0.875″ (22.225 mm)

Housing/bushing width: 0.765″ (19.43 mm)

Outer diameter: 2.325″ (59.05 mm)

Allowable misalignment (α): 5.7°

Unloaded torque / adjustment: without preload

Ultimate static radial load capacity: 84,897 lbs (377,622 N)

Approximate weight: 1.28 lbs (580 g)

Products intended for vehicle modification for competition purposes may render their use prohibited on public roads, insofar as they significantly alter the vehicle's characteristics as specified in the type-approval certificate issued by the relevant authorities (noise level, pollutant emissions, maximum speed, tire dimensions, etc.).
