Wilwood MIDILITE 4 piston brake caliper 38.1mm thickness 21.1mm
Reference:
WI-120-14704
Supplier Ref.:
120-14704
This Wilwood Midilite 4-piston radial mount brake caliper is used as a direct replacement for the Ford M16 caliper on 22mm wide vented discs only.
Type III Mil-Spec hard anodizing replaces Type II black anodizing as the standard finish on all base and powder coat finish caliper models. This process produces a thicker, harder surface with a rich, medium-gray appearance. More importantly, it creates a more durable wear surface in the piston bores, with increased resistance to abrasion and corrosion over the entire external surface of the caliper.Disc thickness: 21.1mm
Disc diameter: 240 to 310mm
Piston diameter: 38.1mm
Mounting center distance: 152mm
Thread: 1/8x27NPT
Sold by unit
Products intended for vehicle modification for competition purposes may render their use prohibited on public roads, insofar as they significantly alter the vehicle's characteristics as specified in the type-approval certificate issued by the relevant authorities (noise level, pollutant emissions, maximum speed, tire dimensions, etc.).16 other products in the same category:
