Fuel barrel pump flow meter

This GT2i Race & Safety rotary hand pump for barrel can be dismantled. It allows a fast effortlessly liquid transfer with a low viscosity, such as fuel. The pump has a dual rotor system which offers an important and constant flow for a reduced effort.

One round equals to a liter.

Pump body in aluminium.

To save space, this rotary pump for barrel can be totally dismantled to ease storage and transportation.

Supplied without oil, the pump mechanism must be lubricated with a SAE 10 oil.

Temperature: -10°C and +55°C
Elbow thread: 32x150
Elbow outlet outer diameter: 32mm
Elbow outlet inner diameter: 29mm

Less detail

This transparent green refuelling hose fits on the M-POMPE-FUT-3 rotary barrel pumps as well as on the G-SPT12-1658-ECO-2 fuel couplers.

Sold by the meter.

Technical specifications:

Inside diameter: 30mm
Outside diameter: 39mm
Length: 1 linear meter

Less detail

If you want to measure the amount of gasoline or kerosene in your vehicle, the PIUSI K24 is the right tool for you.
It is the volumeter for private use that meets the PIUSI K24 requirements, i.e., the use of materials in explosive atmospheres.

With its aluminum body and sealed electronic board, it can be used in all working conditions. The K24 volumetric meter is easy to install, either in line or at the end of the discharge pipe.
It has a multi-position display, which makes it easy to read.

Main features:

- Pulse signal type: single channel, reed switch
- Electronic circuit with LCD display: partial indication 5 digits from 0.1 to 99999, total 6 digits from 1 to 999999.
- Resettable total
- Flow indication
- Repeatability 0.3%.
- Pressure loss < 0,03 bar at 120 l/min
- Calibratable

Note: Remember to calibrate your meter before first use for greater accuracy.

Less detail

Union BSP 1x11 male - Outlet 32mm red aluminium with Viton gasket

Less detail

Hand pump adapter BSP 1x11 male - UN 1-1/4x16 male aluminum red

Less detail

This female fuel coupler is made of light and resistant aluminum.
Mandatory in certain disciplines, this hydraulic coupling is the perfect accessory for filling or taking off fuel for Group R and FIA vehicles.

Use: gasoline

Flow diameter: 12mm

Hose diameter: 32mm

Less detail

90° BSP 1x11 female - female adapter for manual pump.

Less detail
